YN-08-PS-O Potato Harvesting Machine
YN-08-PS-O Potato Harvesting Machine
Thanks to the blades positioned in front of the potatoes, the machine lifts the crop together with the soil and loosens it before depositing it onto the soil surface in rows from the rear of the machine. The potatoes are gently conveyed between the elevator rods without being squeezed, preventing damage to the crop. The machine is mounted to the tractor via a 3-point hitch system and receives its power from the tractor’s PTO shaft. Power transmission to the conveyor system is handled by heavy-duty gearboxes, making the machine highly robust and powerful. Depending on soil structure, the number of elevator rods and rod spacing can be adjusted. With its durable construction, the machine performs reliably in heavy soil conditions, stony fields, and rainy weather. It is especially preferred by large-scale agricultural enterprises.
- Technical Specifications
- Product Images
- Product Video
- Product PDF
Length: 300 cm
-
Width: 180 cm
-
Height: 125 cm
-
Weight: 1000 kg
-
Inner Share Width: 140 cm
-
Digging Depth: Adjustable
-
Number of Digging Blades: 3
-
Elevator Length: 155 cm
-
Elevator Angle: Adjustable
-
PTO Speed: 540 rpm
-
Tractor Speed: 4–6 km/h
-
Capacity: 1–5 decares/hour
-
Required Power: Minimum 65–75 HP
-
Number of Elevator Rods: 72
-
Elevator Rod Spacing: 26–30–38 mm
